Boron carbide Fan 5/8″ Nozzle for Blast Cleaning

Price Each : $479.00

Boron carbide Fan Nozzle.  Is a short light weight (7 oz) fan nozzle, specially designed for close up blast cleaning applications like Cabinet or workshop blast cleaning of small parts. Our Fan nozzle has a flatter and wider blast pattern than a standard short straight bore or short venturi nozzle.  It has similar air needs as a # 4 nozzle.   Fan dimensions 5/8″ Wide  X 5/16″ high.

Weight .5 lbs
Dimensions 3.40 × 1.2 × 1.2 in
color

Silver

Nozzle Liner Material

Model

FAN-816-34

Threads

3/4" NPSM

SKU 10040816

2 in stock (can be backordered)

Add to wishlist Add to compare
SKU: 10040816 Category:

Description

Boron carbide Fan Nozzle (Closed style):

Our Boron Carbide Fan nozzle with its 5/8″ wide fan,  is an especially useful tool for blast cleaning small flat parts in workshop or blast cabinets applications.   Providing a wider rectangular shaped blast pattern than a standard round exit nozzle makes it a very useful tool to have when you need a broad flat blast pattern. It has a Boron carbide liner that is light weight and has a longer wear life than tungsten or silicon carbide.

Features:

  • Light weight
  • Armored Jacket
  • Boron carbide liner
  • 3/4″ NPSM threads
  • Similar air consumption as a # 4 nozzle
  • Wide spray

This fan nozzles is supplied with an armored steel jacket &  are supplied with industry standard ¾” NPSM threads and can be used to blast clean with a wide variety of abrasives including aggressive aluminum oxide!   Similar air requirements as a # 4 standard blast nozzle.

Alternative fan nozzles with 1-1/4″ threads:

If you are looking for a fan nozzle with a large blast pattern for those bigger  blast cleaning jobs, then see our open style fan nozzles.

Fan Nozzles
Fan nozzles for close up blast cleaning e.g. cabinet work.
Model: FAN-816-34
Width:  16 mm / 5/8″ /0.63″
Height:    8 mm / 5/16″ /0.31″
Fan  Size sq. inches:  0.20″
Length: 3.4″
Threads: 3/4″ NPSM
Air Consumption: Similar to # 4 nozzle



Additional information

Weight .5 lbs
Dimensions 3.40 × 1.2 × 1.2 in
color

Silver

Nozzle Liner Material

Model

FAN-816-34

Threads

3/4" NPSM
