Cabinet nozzle EVTC-3F44 with cone/tapered steel jacket
$48.00
Cabinet nozzle EVTC-3F44 with tapered steel jacket and straight 3/16″ bore tungsten carbide liner. Used for close up blast cleaning, typically in cabinets.
| Weight | 0.56 lbs |
|---|---|
| Dimensions | 3 × 2 × 2 in |
| UNSPC | |
| SKU | EVTC-3F44 |
Available on backorder
Add to wishlistAdd to compareFrequently bought together
- Cabinet Nozzle ATV-3$94.00
Description
Cabinet nozzle EVTC-3F44 for close up blast cleaning
Cabinet nozzle EVTC-3F44 tungsten carbide lined blast cleaning nozzle. This 3/16″ straight bore nozzle has a cone/tapered shaped steel jacket that fits blast cleaning guns which use a locking ring to secure nozzle in position.
These tapered nozzles are available with a choice of carbide liners, tungsten carbide for less aggressive abrasives and boron carbide for abrasives like Aluminum oxide. Looking for a larger bore size then take a look at our EVTC-5F44
In addition to these tapered nozzles we offer an extensive range of quality short, straight bore carbide nozzles for close up sandblasting in sand blasting cabinets or spot cleaning for example in automotive applications. These nozzles are fitted with 3/4″ NPSM fine threads please take a look at our UT range.
Specs:
Model: EVTC-3F44
Sku: 754030
Bore: 3/16″
Liner: Tungsten carbide
Shape: Tapered/Cone
Washer: NW34
Replaces part numbers: (T109-3/1910930), (501282/14032), (2-02057), (1090-3)
| Part Number | Model Number | Overall length | Bore inch | Bore mm | O.D. at bottom of jkt | Width at top of jacket |
| 754030 | EVTC-3F44 | 1.75″ / 44.45 mm | 3/16 | 4.80 | 1.12″ / 28.5 mm | 0.925″ / 23.50mm |
| 754031 | EVTC-4F44 | 1.75″/44.45 mm | 1/4 | 6.35 | 1.12″ / 28.5 mm | 0.925″ / 23.50mm |
| 754032 | EVTC-5F44 | 1.75″/ 44.45 mm | 5/16 | 8.00 | 1.12″ / 28.5 mm | 0.925″ / 23.50mm
|
Additional information
| Weight | 0.56 lbs |
|---|---|
| Dimensions | 3 × 2 × 2 in |
| UNSPC | |
| SKU | EVTC-3F44 |
