Boron Carbide Wide-Spray BCI-52W

Description

Boron carbide wide-spray BCI-52W

Boron carbide wide-spray bci-52w, (5/16″) bore, blast cleaning insert, has a wide exit to give a  larger blast pattern.  Larger blast pattern will let the  blast cleaning operator, cover a larger surface area.  Boron carbide is recommended for blast cleaning with more aggressive abrasives.  If you are using aluminum oxide  then our  bci-52w insert will give you more work life than e.g. tungsten carbide.  BCI-52W has a 7/8″ O.D. to fit BNP style blast cleaning guns. (Insert will need a different locking ring and guard).

Blast cleaning with less aggressive abrasives,  look at the tungsten carbide version, TCI-62W (3/8″ bore). for  a smaller blast pattern try our TCI-5 which has a straight bore.

Specifications:

Model: BCI-52W

Sku: 60038

Material: Boron Carbide

Style: Wide-Spray

Bore: 5/16″

O.D.: 7/8″

Length: 2-13/16″

Insert material:

Optimizing blast cleaning nozzle / insert selection can be achieved by choosing a liner material that performs better with the type of abrasive being used.  Below is listed a table showing some indicative work life comparisons for different nozzle/insert liner materials.

Liner Material	Steel Shot / Grit (hours)	Expendable Abrasives (hours)	Aluminum Oxide (Hours)
Ceramic	20-40	10-30	1-4
Tungsten Carbide	500-800	300-400	20-40
Silicon Nitride / Carbide	600-1000	400-600	50-100
Boron Carbide	1500-2500	750-1500	200-1000

All figures is above table are indicative & given for comparison purposes only and nozzle service life will depend on variables such as blast pressure, media dimensions and profile.
